IMV25 Multivariable Pressure Transmitter

The Foxboro IMV25 multivariable transmitter transmits digital process measurements of pressure, differential pressure, and process temperature, as well as internal sensor and electronics temperatures. It is an ideal solution when a number of individual measurements are to be brought into a system for monitoring, control, or calculation. The IMV25 is available with a choice of HART, Modbus, Foundation Fieldbus, or FoxCom digital communications. A single 4 to 20 mA analog output is also provided.



Key Benefits

  • Simple, elegant sensor packaging uses very few parts to achieve exceptionally high reliability
  • Liquid Crystal Display (LCD) digital indicator with on-board pushbutton configuration and calibration.
  • NEMA 4X and IEC IP66 durable epoxy-coated aluminum, or 316 ss housings.
  • Co-Ni-Cr, 316L ss, and Nickel alloy (equivalent to Hastelloy®(1)) sensor materials for all transmitters.
  • Can be provided with numerous configurations of direct connect or remote mount seals.
  • Integral process connections for sanitary, and pulp/paper installations.
  • Rugged & Dependable: Field-proven silicon strain gauge technology and corrosion-resistant epoxy finish
  • Long term stability is excellent as drift is less than ±0.05% of URL per year over a 5-year period for both DP and P measurements
  • Minimized static pressure effect on DP by using pressure to compensate the DP measurement
  • Excellent ambient temperature effect compensation due to characterization and microprocessor-based compensation
  • Best in the industry – 5 year warranty; 17 year optional.
Document title Document type Document Date Download
Specification guide 01/06/2007
Data Bulletin 01/03/2005
Specification guide 01/12/2012
Technical leaflet 01/09/2004
Technical leaflet 01/11/2004
Specification guide 01/10/2004
Specification guide 01/12/2012
Specification guide 01/11/2008
