SMP981 Pneumatic Position Transmitter

  • Non-reactive conversion of stroke position into a 0.2 to 1 bar pneumatic standard signal
  • Simple installation and adjustment
  • Zero and range settings non-interactive
  • Attachment according to DIN IEC 534 part 6 (NAMUR)
  • Robust, corrosion protected design
  • Simple matching to strokes of 8 to 115 mm and, by means of rotary adapter, to angular displacements of 30° to 120°
  • Protection class IP 54

The SMP981 converts the linear or rotary movement of valve actuators into a 0.2 to 1 bar pneumatic signal.

Los accesorios necesarios para el funcionamiento y el montaje – descarga Kits de Montaje.

Para mas información vaya la solapa Documentacion en la parte superior de esta página

Document title Document type Document Date Download
Specification guide 01/07/2015


         Attachment-kits TI EVE0011 A_001                             Attachment kits for positioners
Technical leaflet 05/2016
